POE RJ45 Connector Embedded Serial-to-Ethernet Modules 0826-1X1T-AD-F

Ask Lasest Price
Brand Name :	LINK-PP
Model Number :	0826-1X1T-AC-F
Certification :	ISO9001,SGS,UL,CE,REACH
Price :	$0.09-$1.85
Payment Terms :	TT,NET30/60/90 Days
Supply Ability :	3000000/Month
Delivery Time :	Stock

Add to Cart

Product Details
Company Profile

POE RJ45 Connector Embedded Serial-to-Ethernet Modules 0826-1X1T-AD-F

Quick Details

0826-1X1T-AD-F
Industrial PoE Switch High PoE active Power Over Ethernet Splitter
Bel - MagJack Integrated Connector Modules
MagJack® Integrated Magnetics Modular Jacks
10/100/1000 Base-T, AutoMDIX
Through Hole,Shielded, EMI Finger,90° Angle (Right)
RJ45 Connector with integrated transformer & POE
ISO9001,SGS,UL,CE,REACH
Customers:TI,Intel,GE,Sony,Samsung
Other Name: LPJK0043AONL

Features

Power Over Ethernet (PoE) Magnetic Connectors with Tab-Up and Tab-Down with/without LED's and EMI tabs
Single port, Multi-port and Stackable configurations (Thru-hole)
Reduces the number of components to be placed on the board
Frees up board space and offers signal protection
Noise reduction in the system
Improved reliability and optimal system performance
Benefits of having shorter signal paths and the reliability gains from systems containing fewer components
Helps manufacturers reach their goals of cost reduction

Specifications

Characteristics	Embedded Serial-to-Ethernet Modules 0826-1X1T-AD-F POE RJ45 Connector
	2)SMD,THT and THT with USB
	3)350μH min,OCL with 8mA bias
	4)Complies with IEEE 802.3
	5)Extended temperature range 0°c~70°c ( or -40°c~+85°c ) available
	6)PoE/PoE+ (350mA~720mA)
Operation/Application	×DSL Modems
	EMbedded PC
	LAN Applications
	Hub,Router,Switches
	AVR,DVR
Electrical Character
Shielded	with/without
Termination Features
EMI Finger	with/without
Termination Method	Solder
Body Features
LED	with/without
EMI Fingers - Top and Sides	with/without
Latch Orientation	Tape UP/Down
PCB Tail Length	3.5±0.5mm
Height Above Board	0.536" (11.15~13.61mm)
Contact Features
Preloaded	YES
Contact Termination Type	Through Hole
Connector Style	Jack
Cores Number	8
Industry Standards
EoHS/ELV Copliance	RoHS compliant,ELV compliant
Lead Free Solder Process	Wave solder capable to 265°c
RoHS/elv Compliance History	Always was RoHS Compliant
Conditions for Usage
Applies To	Printed Circuit Board
Environmental Conditions	Office / Premises
Operating Temperature(°c)	0°c~70°c / -40°c~+85°c
Other Features
Magnetic Circuit	3D15
Status Indicator	LED
Left LED Color	Green / Yellow / Orange / Red / Blue
Right LED Color	Green / Yellow / Orange / Red / Blue
Decoupling capacitor	with/without
Rear PCB Ground Tab	with/without
Singal Lead Quantity	8
Datasheets	E-mail Inquiry to Summer@link-PP.com

BeagleBone Black

LINK-PP RJ45 Designed for BeagleBone Black of Texas Instrument

http://www.ti.com/tool/beaglebk#0

a low-cost, open source, community-supported development platform for ARM® Cortex™-A8 processor developers and hobbyists.

LINK-PP ------------ The Appointed Supplier And Supporter Of Embedded System for Ti

Related PN

We Can Also Make These Part Number Below
XMP-P11-10F0-GY-CT1	XMH-01R-4-DZ5-1-170
XMP-P25-10F0-GY-CT1	XMH-01-5-PL2-111-1P0
XMP-01-4-P25-111-1P0	XMG-01-4-P23-111-1P0
XMP-P31FAT-10F0-NL	XMP-01-4-P25-111-1P0
XMH-T02-041-423-012	XPJG-1-01K-5-PN1-210
XMP-9808-81011-140D-T3	XPJG-1-01A-4-D51-310
XMH-9771-8812-S3L2T2-EU	XPJG-1-01A-4-D51-110
XMP-XARJ-1032NL	XPJG-1-01-8A-G31-1-PD31
XMPH-TRJK0013AHNL-GE1	XPJG-01J-1-P31-110
XMPH-TRJK2001AHNL	XMH-PD2F-10H0-GY
XMPH-061Q-12F6-GY(RMP-061Q-12F6-GY)	XPJH-RMP-061L-10W6-NL
XMPH-01D-1-D25-110	XMP-RMP-LC4P-16F6-NL
XMPH-01R-4-Q23-170	XPH-RMP-061L-16W6-2Y
XMPH-XARJ-8017CNL	XPJH-RMP-061K-16W6-NL
XMPH-SC851-901NL	XMG-TRJ4190GENL
XMP-TRJK0010AGNL	XMH-TRJ6100AGNL-SG1
XMH-TRJ16003AZNL	XPJH-01D-1-D25-110(XMH-01-1-PP1-111-1P0)
XMH-TRJ1514AENL	XMP-01M-0-H61-11P
XMP-TRJ16249AZNL	XMP-01D-4-L61-11P
XMPH-TRJK4013AHNL	XMP-01J-1-P12-C01
XMP-061K-16W6-2Y-M	XPJH-1-01-8C-E3M-4-PD11
XMP-01J-1-P12-T01	XPJH-01D-4-PG1-170-DAQ
XMP-9774-TF91121-006-CX1	XPJH-01D-4-P23-170-DAQ-C
XMP-1104D6014	XPJH-01D-4-P23-170-DAQ
XMP-TRJK1046AONL	XPJH-01D-0-PH1-070
HRJ-YL1B11M2000BNL	XPJH-01F-4-P25-176
XPJH-01L-4-R07-170	XPJH-01F-5-PN1-170
XPJH-01R-0-Q22-07C-OAS	XPJH-01R-0-PJ1-07K-BRD
XPJH-01R-0-R09-070	XPJH-RN6-1640F51F
XPJH-061LAT-10W6-NL	XMH-YL5917222X6PLE
XPJH-01R-0-F02-070	XPJH-1-26-8A-S4C-0-PD01
XPJH-061KAT-16W6-NL	XPJH-28A-Z-P01-970
XPJH-01R-4-D11-171	XPJH-28D-0-H65-070
XPJH-1-01-8A-C41-4-PE11	XPJH-28D-0-H01-01
XPJG-01J-4-P25-110	XPJH-2-28-8C-T4D-0-PH01
XPJG-01J-1-P28-110	XMH-YL5917122X1LE
XPJG-01J-4-PH2-110	XMH-YL5917212X1LE
XPJG-01K-5-PN1-210	XPJH-21D-Z-P21-970-MHF
XPJG-01A-4-D51-310	XPJH-1-21-8A-Q30-Z-PD21
XPJG-01A-4-D51-110	XPJH-TRJ17002A109NL
XPJG-1-01-8A-G31-1-PD31	XPJH-1-21-8A-Q30-4-PD22
XMG-TRJ26514AENL	XMH-9760-DH3B120-286
XPJH-1208C1009	XPJH-24A-Z-P01-970
XPG-SK02-411008POENL	XMH-YL5917222X4PLE
XPJG-1-04-8A-G34-4-PD23	XPJH-24D-Z-P21-970-MHF
XPJH-04L-8-R08-4V0	XMH-9760-DH3D120-286
XPJH-04L-8-R08-4V0-JU	XPJH-26A-Z-P01-970
XPJH-04L-5-R10-1S0	XMH-9760-DH3G130-286
XPJH-04D-1-D34-190	XPH-TRJ46253AENL

Order Guide

Embedded Serial-to-Ethernet Modules 0826-1X1T-AD-F POE RJ45 Connector
Type PCB Mount	Thru-Hole (THT)
Number of Ports	1, 2, and 4 Ports and Stackable 2x1, 2x2, 2x4, 2x6 and 2x8
Shield and Unshield	Available in Shield and Unshield
Connector Type	RJ45
PoE	Power Over Ethernet Integrated
Magnetics	Magnetic Integrated
Magnetics Speed	Magnetics 10/100Mbps and 1Gigabit
Packaging	Tray Options
Tab Location	Tab Up and Tab Down Options
LED Color	Optional
Number of Positions	8 and 10 Positions or Others
Number of Contacts	8 and 10 Contacts or Others
RoHS Compliant	Yes
Solder Temperature	230 TO 240 degr.C 5-10 SECONDS
Solder High-Temp Option	260 degr.C 5-10 SECONDS
High Temperature Option	-40 to +85 Degrees F
Operating Temperature	-0 to 70 Degrees C

Embedded Serial-to-Ethernet Modules 0826-1X1T-AD-F POE RJ45 Connector
