Name: HR916130HE 1000 BaseT 2x1 Port Stacked RJ45 Connector UL LPJG17610AANL
Brand: LINK-PP
Price: 0.05 USD

Add to Cart

HR916130HE 1000 Base-T 2x1 Port Stacked RJ45 Connector UL LPJG17610AANL

Category
Category	RJ45 connector -PCB Socket 8P8C
Filter	1000 Base-T
Entry Angle	90° Angle
LED	No
Color - Resin	Black
Electrical
Current - Maximum per Contact	1.50A
Voltage - Maximum	125V
Contact Resistance	30 mΩ Max
Insulation Resistance	500 MΩ Min
Withstanding Voltage	1000V AC r.m.s
Temperature Range operating	-40ºC~+85ºC
Material and Plating
Material-Metal	Phosphor Bronze
Material - Plating Mating	Gold
Material - Plating Termination	Gold
Material - Resin	PBT UL94V-0

Why Choose Us

World’s Leading Supplier Of Integrated RJ45 Connectors and Discrete Magnetic Transformers
