    SS-6546-NF RJ45 Modular Jacks Unshielded Vertical Orientation

    Ask Lasest Price
    Brand Name : LINK-PP
    Model Number : LPJ0011BBNL
    Certification : UL,ROHS,Reach,ISO
    Price : $0.06-$0.8
    Payment Terms : TT,NET30/60/90 Days
    Supply Ability : 4200K-PCS/Month
    Delivery Time : Stock
    • Product Details
    • Company Profile

    SS-6546-NF RJ45 Modular Jacks Unshielded Vertical Orientation


    Specifications of Unshielded Modular Jacks:

    • Connector Type: Modular Jacks
    • Part Number: SS-6546-NF
    • Gender: Jack (Female)
    • Number of Positions/Contacts: 6p4c (RJ11, RJ14)
    • Number of Ports: 1
    • Number of Rows: 1
    • Mounting Type: Through Hole
    • Orientation: Vertical
    • Termination: Solder
    • Shielding: Unshielded
    • Features: Board Lock
    • LED Color: Does Not Contain LED
    • Color: Black
    • Housing: Thermoplastic Ul94 V-0
    • Contacts: Copper Alloy
    • Contact Plating: Selective Gold In Contact Area

    SS-6546-NF (LPJE615-1NNL) RJ45 Datasheet:


    LPJE615-1NNL.pdf



    Notes of 6P4C Vertical RJ45 Jack:


    MATERIAL:

    1. CONTACT WIRE: 0.46MM DIAMETER PHOSPHOR BRONZE OPTIONAL GOLD PLATING OVER NICKEL

    2. DURABILITY: 1000 MATING CYCLES MIN

    ELECTRICAL:

    1. CURRENT RATING: 1. 5A

    2. VOLTAGE RATING: 125VAC RMS

    3. CONTACT RESISTANCE: 20MΩ MAX

    4. INSULATION RESISTANCE:100MΩ MIN

    5. WITHSTANDING VOLTAGE:1000V AC FOR 1min.

    6. GOLD PLATING: (GOLD FLASH:1.5; 3; 6; 15; 30; 50)U" INCH

    7. (1) STORAGE TEMPERATURE RANGE:-40℃ to +85℃

    (2) 0PERTIONTEMPERATURE RANGE: -40℃ to +85℃

    (3)WAVE SOLDER TEMPERTURE: 230C to 250℃5~10 SEC.


    Details of SS-6546-NF 6P4C Jack:
